Cleanroom Partitions

Trio India Design, Manufacture, Supply and Install complete Clean Room Modular Flush Sandwich Panels / Partitions. Our Panels are manufactured with Galvanized Steel Sheet (G.P.S.P) / Stainless Steel SS304/ Pre Painted Sheets. These Sandwich Panels / Partition are relocatable and easy to install as required, and tailor-made as per Customer Requirements.

The partition is modular and demountable. Its construction concept makes it truly economical and can be customized in various finishes, depending on the application. We work with the concept of Progressive and Non- Progressive partition in this industry, The panels are non-particle shedding, load-bearing, walkable panels and feature pre-formed cut-outs for the housing of HEPA filters and other dedicated services.

partitions min

Highlights of our Partitions

  • All our Sandwich Panels / Partitions are prefabricated with cutouts. conduits and with factory fitted Vision Panel which is supplied for ready Installation at the site.
  • All panels are insulated with Polyurethane Foam / Rock Wool insulation and as per customers requirement.
  • Modular inbuilt risers of different thicknesses are made with required perforated SS-304 / GPSP Powder Coated Riser Grills.

Advantages

  • Demountable/Relocatable (Facility can be dismantled and shifted easily without damage or loss of modules or components).
  • Modular and Light Weight Construction.
  • Painting and Maintenance Free.
  • Sheet Metal and Aluminium Profiles with Flush & Coved Powder Coated Panels does not allow Micro-organisms growth.
  • Erection and Installation can be done with speed and ease.
  • Easy to Clean & Maintain.
  • Operation Flexibility and Durability.
  • Colour Choice as per RAL series.

Specifications

Panel Width: Max 1200mm / Customized, as standard. Panel thickness ranges from 25 mm to 150 mm
Panel Height: Up to 3700mm with provision to have stacked panels for higher-level applications
Base Detail: Raised / C-Type Base
Infill Material: Rock Wool & Polyurethane Foam
Surface Finish: Pure Polyester Powder coated as per RAL colours, SS Finish (matt/ mirror finish)
Glazing: Double flush glazing with 5mm toughened glass having a ceramic border on both sides within a stainless steel framing
Air Leakage: Silicon Sealant for sealed application
